Tipi ta 'Prodott: Fittings tat-tubi tas-siġill tal-wiċċ BF o ring
Istandards tal-Industrija: SAE J1453, ISO 8434-3, SAE J514, ISO 8434-2
Konnessjoni mill-istil E għall-F: ORFS MALE / ORFS FEMALE / ORFS MALE
Forma: Minkeb, dritta, Tee, Salib eċċ.
Fittings ORFS Klassifikazzjoni tal-pressjoni tax-xogħol: 3215 psi sa 5800 psi, 216 bar sa 400 bar.
Orf tal-wiċċ ċatt jew kit daqsijiet taċ-ċirku u disinn ta 'siġill tal-wiċċ O ring aħna wkoll nistgħu noffrulek.
Differenza bejn siġill tal-wiċċ o ċirku u siġill tal-boxxla ċirku
Materjal tal-Fittings: Brass; Azzar tal-karbonju; Stainless Steel
Applikazzjoni: Tagħmir Agrikoltura, Proċess tal-Karozzi, Trasferiment Kimiku, Tagħmir tal-Kostruzzjoni, Trasferiment tal-Fjuwil, Idrawliku, Tagħmir tal-Manifattura, Baħar, Immaniġġjar tal-Materjal, Tagħmir Mobbli, Qasam taż-Żejt, Ippakkjar, Trasport
BF ORFS MALE / ORFS FEMALE / ORFS MALE BD-Dimension Tabella tal-qisien kif ġej:
PARTI LE. | TAN | O O-RING | Dimensjonijiet | |||||||||
E | F | Ġ | E | Ġ | A | B | Ċ | S1 | S2 | |||
BF-04 | 9/16 "X18 | 9/16 "X18 | 9/16 "X18 | 7.65X1.78 | 7.65X1.78 | 23 | 8.5 | 23 | 14 | 19 | ||
BF-06 | 16/11 "X16 | 16/11 "X16 | 16/11 "X16 | 9.25X1.78 | 9.25X1.78 | 27 | 10 | 27 | 19 | 22 | ||
BF-08 | 13/16 "X16 | 13/16 "X16 | 13/16 "X16 | 12.42X1.78 | 12.42X1.78 | 31 | 11 | 31 | 22 | 27 | ||
BF-10 | 1 "X14 | 1 "X14 | 1 "X14 | 15.6X1.78 | 15.6X1.78 | 36.5 | 13.5 | 36.5 | 27 | 30 | ||
BF-12 | 1.3 / 16 "X12 | 1.3 / 16 "X12 | 1.3 / 16 "X12 | 18.77X1.78 | 18.77X1.78 | 40.3 | 15 | 40.3 | 30 | 36 | ||
BF-16 | 1.7 / 16 "X12 | 1.7 / 16 "X12 | 1.7 / 16 "X12 | 23.52X1.78 | 23.52X1.78 | 44.5 | 15 | 44.5 | 36 | 41 | ||
BF-20 | 1.11 / 16 "X12 | 1.11 / 16 "X12 | 1.11 / 16 "X12 | 29.87X1.78 | 29.87X1.78 | 47.5 | 15 | 47.5 | 41 | 50 | ||
BF-24 | 2 "X12 | 2 "X12 | 2 "X12 | 37.82X1.78 | 37.82X1.78 | 53.5 | 15 | 53.5 | 50 | 60 | ||
