Il-katalgu tal-fittings BSP huwa popluare fir-Renju Unit, l-Irlanda, il-Kanada, l-Istati Uniti eċċ.
It-tagħmir kollu tal-koni BSP 60 huwa spjegat mill-BS5200 daqs l-istandard ISO 8434-6.
Id-daqs tat-tabella tad-daqs tal-ħajt BSPP huwa G 1/8, G1 / 4, G1 / 2, G3 / 4, G3 / 8, G5 / 8, G1, G1-1 / 4, G1-1 / 2, G2, G2- 1/2, G3 eċċ.
BSP huwa pajp standard Brittaniku b'għamla ta '55 grad.
Il-ħajt BSPP huwa skond l-istandards ISO 228 u AS 1722.2.
Gwida tal-ħajt BSPP għal ħafna tipi ta 'siġillar bħal BSPP 60 ° kon għal tubu tas-sedil konnettur, port BSPP bis-siġill imwaħħal, port BSPP bis-siġill ED, BSPP oring + żamma taċ-ċirku tat-tip G, BSPP o-ring aġġustabbli tat-tip H, wiċċ tat-tqattigħ BSPP Siġill tat-Tip B.
Adattaturi tat-twaħħil tal-pajpijiet BSPP għal ħafna truf bħal BSPT maskili, maskili ORFS, metrika ISO 6149-3 stud, maskili JIC 74 kon, Komatsu metrika 60 kon, maskili NPT, SAE ORB ISO 11926-3, tagħmir ta 'weldjatura butt, femminili JIC 37cone, ORFS femminili eċċ.
1B-WD BSP GĦAMLA UŻU DOPPJU GĦAL 60 ° CONE SEDIL JEW SIĠILL BONDED / BSP MALE MAS-SEĦLA KAPTIVA It-tagħmir tad-daqs tat-tabelli kif ġej:
PA RT N O. | T HR EA D | C AP T I V E | DIM E N S I O NS | ||||
E | F | F | A | B | L | S 1 | |
1 B - 04 W D | G 1/4 " X 19 | G 1/4 " X 19 | W D - B 04 | 12 | 12 | 32 | 19 |
1 B - 04 - 06 W D | G 1/4 " X 19 | G 3/8 " X 19 | W D - B 06 | 12 | 12 | 34.5 | 22 |
1 B - 04 - 08 W D | G 1/4 " X 19 | G 1/2 " X 14 | W D - B 08 | 12 | 14 | 39 | 27 |
1B 06 W D | G 3/8 " X 19 | G 3/8 " X 19 | W D - B 06 | 13.5 | 12 | 34 | 22 |
1 B - 06 - 08 W D | G 3/8 " X 19 | G 1/2 " X 14 | W D - B 08 | 13.5 | 14 | 40.5 | 27 |
1B 08 W D | G 1/2 " X 14 | G 1/2 " X 14 | W D - B 08 | 16 | 14 | 43 | 27 |
1 B - 08 - 12 W D | G 1/2 " X 14 | G 3/4 " X 14 | W D - B 12 | 16 | 16 | 46 | 32 |
1B 12 W D | G 3/4 " X 14 | G 3/4 " X 14 | W D - B 12 | 18.5 | 16 | 46.5 | 32 |
1 B - 12 - 16 W D | G 3/4 " X 14 | G 1 " X 11 | W D - B 16 | 18.5 | 18 | 52.5 | 41 |
1B 16 W D | G 1 " X 11 | G 1 " X 11 | W D - B 16 | 20.5 | 18 | 54.5 | 41 |
1 B - 16 - 20 W D | G 1 " X 11 | G 1.1 / 4 " X 11 | W D - B 20 | 20.5 | 20 | 58.5 | 50 |
1B 20 W D | G 1.1 / 4 " X 11 | G 1.1 / 4 " X 11 | W D - B 20 | 20.5 | 20 | 58.5 | 50 |
